Skirting radiators

Skirting radiators have been an important part of the production program since the start of HPM Therm manufacturing activity. They are a suitable aesthetic accessory in the HVAC industry. In the current trend of modern building insulation, skirting radiators are used more and more. This is because of their heating economy and pleasing design.

The following versions are in our basic offer:



ROMA 30
STANDARD DuO QUATRO


TURÍN 30 MERAN 30
STANDARD DuO STANDARD DuO


Version with marking
31 (Water distribution in skirting) 32 (Electro channel) Water distribution casing



Table of basic measures



Type Length (mm) Height (mm) Depth (mm) Heat performance
ROMA Standard 30 basic module
800 mm

Additional module
400 mm
267 96 from 376 up to 865 Watt
for 1 b.m. and drop of temperature 75/65/20°C
Standard 31 286
DuO 30 282
DuO 31 301
QUATRO 30 277 180
TURÍN Standard 30 282 96
Standard 31 301
DuO 30 327
DuO 31 346
MERAN Standard 30 282 96
Standard 31 301
DuO 30 327
DuO 31 346

  • ROMA QUATRO is delivered assembled
  • All the other types are delivered in parts – LEGO system


Table of basic materials



  ROMA 30, 31 TURÍN 30, 31 MERAN 30, 31
Standard, DuO, Quatro Standard, DuO Standard, DuO
material Paneling (wood) beech continuous, spruce (oak) beech mosaic (oak) spruce
Radiator body copper (tubes), aluminium (fins)
Brackets aluminium + additional pads

More information in prospects.



Prospect and pricelist for download here
