Heat exchangers

HPM Therm produce finned water/air heat exchangers in five geometries with tubes 5/8" and 1/2 " tubes.

They are applied as follows:

  • water and steam heaters
  • water and glycol coolers
  • thermal recovery air-water-air (incl. High Efficiency Heat Recovery)
  • freon exchangers for evaporation
  • freon exchangers for condensation


Geometry   BR.W BR.G HR.W
Tube Cu 1/2" x 0,35 (0,7) mm 1/2" x 0,35 (0,7) mm 5/8" x 0,4 (0,8) mm
Tube spacing   38 x 33 38 x 33 60 x 30
Fin form   corrugated smooth corrugated
Fin thickness  Al 0,12; 0,15; 0,20; 0,25 0,12; 0,15; 0,20; 0,25 0,12; 0,20; 0,25
   AE 0,12; 0,15; 0,20 0,12; 0,15; 0,20  0,12; 0,18
  AH 0,15 0,15
   Cu 0,12  0,12 0,12
Fin spacing   1,6mm  - 8 mm 1,6mm - 8 mm 1,6mm - 6,5mm
Header   steel , copper
Frame   galvanized steel, aluminium , copper , stainless steel






Geometry

  HS.W HZ.G
Tube Cu 5/8" x 0,4 (0,8) mm 1/2" x 0,35 (0,7) mm
Tube spacing   30 x 30 30 x 30
Fin form   corrugated smooth
Fin thickness  Al 0,12; 0,15; 0,20; 0,25 0,12; 0,15; 0,20; 0,25
   AE 0,12; 0,15; 0,12; 0,15; 0,20
  AH - -
   Cu 0,12; 0,18  0,12; 0,18
Fin spacing   1,6mm  - 5 mm 1,6mm - 4 mm
Header   steel , copper
Frame   galvanized steel, aluminium , copper , stainless steel








Prospect for download here:
